IPC 2221B

$101.00

Generic Standard on Printed Board Design

Published by Publication Date Number of Pages
IPC 11/01/2012 184

Description

IPC 2221, Revision B – Generic Standard on Printed Board Design

IPC 2221 is the foundation design standard for all documents in the IPC-2220 series. It establishes the generic requirements for the design of printed boards and other forms of component mounting or interconnecting structures, whether single-sided, double-sided or multilayer. Among the many updates to Revision B are new criteria for conductor characteristics, surface finishes, via protection, board electrical test, dielectric properties, board housings, thermal stress, compliant pins, panelization and internal and external foil thicknesses. Appendix A provides new test coupon designs used for lot acceptance and quality conformance testing.

Product Details

Published:
11/01/2012
Number of Pages:
184
File Size:
1 file , 3.8 MB
Product Code(s):
2221-STD-0-D-0-JP-B
Note:
This product is unavailable in Russia, Ukraine, Belarus
